Description
The PROwatt SW Series feature True Sine-Wave AC output with 2000 watts. With high surge capability, the PROwatt SW Series provides the necessary current to startup demanding electrical loads. In addition to dual GFCI AC receptacles, the PROwatt SW Series include an innovative USB connection for providing power to most USB chargeable devices. The PROwatt SW Series offers many safety features not found in similar inverters. When equipped with a remote control, the PROwatt SW Series has the ability to provide automatic ignition lockout shutting down the inverter’s output when the vehicle’s ignition is not engaged.
The compact, easy-to-use and easy-to-install design of the PROwatt SW Series makes it ideal for use in commercial truck, RV and marine applications. With True Sine-Wave output, the PROwatt SW Series can provide power for all types of electrical loads including, variable speed power tools, advanced electrical
appliances, microwaves and much more. The PROwatt SW provides household AC power anywhere.
Product Features
2000 watts maximum, 1800 watts continuous, 3000 watt surge capability
Built-in digital display for DC volts and output power
Built-in USB port
Dual GFCI AC receptacles for safe operation
Heavy duty terminals for trouble-free battery connection
Available optional ON/OFF remote switch (with ignition lockout)
Two year warranty
Protection Features
Low voltage shutdown (10.5 Vdc)
Low voltage alarm (11.0 Vdc)
Over voltage protection (15.5 Vdc)
Over load shutdown
Over temperature shutdown
GFCI protection
PROWatt SW 2000 Specifications
Electrical Specifications
Model
PROWatt SW 2000
Maximum AC Power
2000 W maximum – 1800 W continuous
Surge capacity (peak)
3000 W
DC input
12 Vdc (nominal)
AC output frequency
60 ± 0.05 Hz
AC output voltage range
104 – 127 Vac
USB output
5 V / 500 mA
Output waveform
True Sine Wave
Optimum efficiency
90%
No load current draw
< 0.8 A
Input voltage range
10.5 – 15.5 Vdc
General Specifications
Output temperature range
32°F to 104°F (0°C to 40°C)
AC receptacle
Dual GFCI
USB receptacle
Single port (Type A)
DC connection
Hardwire
Recommended DC fuse
150 A
Digital display
DC voltage, AC output power & error codes
Dimensions (L x W x H)
3.9 x 11.8 x 13.7″ (100 x 229 x 348 mm)
Weight
10.7 lb (4.9 kg)
Warranty
Two year
Part number
806-1220
Optional Accessories
Remote panel with 25” remote cable
808-9001
50” remote cable
31-6262-00
Regulatory Compliance
UL458 – 5th Edition – Power Converters/Inverters and Power Converter/Inverter Systems for Land Vehicles and Marine Crafts
CSA 107.1-01 (R2006) – General Use Power Supplies
EMC: FCC Part 15, Class A
Note: Specifications subject to change without notice.
